Welding Plate Flange JIS B2220 JIS B2238 5K 10K 20K 50A-300A

Name:Slip on Plate flange Standard:AWWA C207, JIS B2220, BS 3293, SANS 1123 Material:Stainless Steel, Carbon Steel Specifications:1/2"-24" DN15-DN1200 Scope of application: PN2.5~PN40; Class150~Class1500 Connection mode:Welding Production method:Forging Acceptance: OEM/ODM, Trade, Wholesale, Regional Agency, Payment: T/T, L/C, PayPal Any inquiries we are happy to reply, please send your questions and orders. Stock Sample is Free & Available

Products Details

Product introduction

Flat welding flange refers to a flange connected with vessels or pipes by fillet weld. There are two types of flange ring: with neck and without neck. Compared with the neck butt welding flange, the flat welding flange has simple structure and low material consumption. The flat welding flange is widely used for the connection of medium and low pressure vessels and pipelines.

Characteristic

1. The flat welding flange not only saves space and reduces weight, but also ensures that the joint will not leak and has good sealing performance. The reason why the size of the compact flange is reduced is that the diameter of the seal is reduced, which will reduce the section of the sealing surface.
2. The flange gasket has been replaced by the sealing ring to ensure that the sealing face matches the sealing face. In this way, only a small pressure is required to compress the sealing surface.
3. Flat welding flange is a relatively high-quality flange product, which reduces the quality and space and plays an important role in industrial use.

Material and Process

Stainless steel flange: ASTM A182 F304, 304L, F316, 316L

Production processes: sawing, heat treatment, die forging, machining

Pressure

PN0.25MPa, PN0.6MPa, PN1.0MPa, PN1.6MPa, PN2.5MPa,PN4.0MPa
